8-Bay SFF · 8 × 2.5 in
Uses hot-swap 2.5-inch drives for dense, power-efficient storage. Dual 2nd-Gen Intel Xeon® Scalable CPUs, two PCIe slots and up to 24 RDIMMs at 2933 MT/s.
Does your data centre need a secure, performance-driven, dense server for virtualisation, database, or high-performance computing workloads? The HPE ProLiant DL360 Gen10 delivers security, agility and flexibility without compromise. Powered by Intel® Xeon® Scalable processors (up to 28 cores) and up to 3 TB of 2666 MT/s HPE DDR4 SmartMemory, it provides up to 71 % higher compute performance and 66 % faster memory bandwidth compared with the previous generation.
With support for 12 NVDIMMs and up to 10 NVMe drives, the DL360 Gen10 accelerates transactional workloads while preserving rack density. HPE OneView and HPE iLO 5 automate the entire server life-cycle—deploy, update, monitor and maintain—so you can confidently roll out this secure 2-socket platform in space-constrained environments.
| SKU | CPU / Memory | Drive Bays | Controller | PSU | Tier |
|---|---|---|---|---|---|
| 867961-AA1 | Xeon Bronze 3106 • 1 P • 16 GB | 8 SFF | S100i SATA RAID | 1 × 500 W | Entry |
| 867962-AA1 | Xeon Silver 4114 • 1 P • 16 GB | 8 SFF | P408i-a SAS RAID | 1 × 500 W | Base |
| 867963-AA1 | Xeon Gold 5118 • 2 P • 32 GB | 8 SFF | P408i-a SAS RAID 25 GbE 640FLR |
2 × 800 W | Performance |
| 867964-AA1 | Xeon Gold 6130 • 2 P • 64 GB | 10 NVMe | P408i-a SAS RAID 25 GbE 640FLR |
2 × 800 W | Hi-Perf |
| 879991-AA1 | Xeon Gold 6130 • 2 P • 64 GB | 10 NVMe | P408i-a SAS RAID 25 GbE 631FLR |
2 × 800 W | Hi-Perf |
| Q8Z98A | Xeon Bronze 3104 • 1 P • 16 GB | 8 SFF | H240ar 12 G HBA | 1 × 500 W | Entry (HBA) |
| Q8Z99A | Xeon Bronze 3106 • 1 P • 16 GB | 8 SFF | P408i-a SAS RAID | 1 × 500 W | Entry+ |
| Q9A00A | Xeon Silver 4108 • 1 P • 16 GB | 8 SFF | P408i-a SAS RAID | 1 × 500 W | Base |
| Q9A01A | Xeon Silver 4110 • 1 P • 32 GB | 8 SFF | P408i-a SAS RAID | 1 × 500 W | Base+ |
Powered by Intel® Xeon® Scalable processors with up to 28 cores and 2666 MT/s DDR4 SmartMemory (up to 3 TB), the DL360 Gen10 delivers up to 71 % higher compute performance and 66 % faster memory bandwidth versus the previous generation. Support for 12 NVDIMMs and up to 10 NVMe SSDs further accelerates transactional and analytical workloads.
Mix LFF, SFF and NVMe drives in the same 1U chassis: choose 4 LFF, 8 SFF or 10 NVMe front-bay configurations, with an optional rear SFF/uFF kit. Three PCIe 3.0 slots and embedded 4×1 GbE—with optional 10/25 GbE or InfiniBand adapters—provide ample I/O headroom for evolving workloads.
Silicon Root of Trust anchors firmware security at the hardware level. Runtime Firmware Verification checks critical firmware every 24 hours, and Secure Recovery automatically rolls back to the last known-good image if tampering is detected. Optional TPM 2.0 and an Intrusion Detection Kit add further protection.
Integrated iLO 5 and OneView automate deployment, monitoring and updates, while HPE Pointnext services—Flexible Capacity, Datacenter Care and Proactive Services—reduce risk and accelerate time-to-value for infrastructure roll-outs.
| Processor Family | Intel® Xeon® Scalable 8100 / 6100 / 5100 / 4100 / 3100 Series |
|---|---|
| Cores per CPU | 4 – 28 cores (model dependent) |
| Max Memory | 3 TB (24 × 128 GB DDR4-2933 SmartMemory) Up to 12 NVDIMMs (192 GB total) |
| Drive Bays | 4 LFF SAS/SATA/SSD 8 or 10 SFF SAS/SATA/SSD 10 premium SFF NVMe Optional 1 × rear SFF or dual uFF |
| Storage Controllers | Smart Array P408i-a, P816i-a or E208i-a Gen10 (model dependent) |
| Expansion Slots | 3 × PCIe 3.0 |
| Network | Embedded 4 × 1 GbE 331i Optional FlexibleLOM / stand-up 1/10/25 GbE |
| Form Factor | 1U rack |
| Power Supplies | Up to 2 × Flex Slot hot-plug (500 W / 800 W / 1600 W) |
| Cooling | Hot-plug redundant fans (N+1) |
| Dimensions (W × D × H) | 43.46 × 70.7 × 4.29 cm (17.11 × 27.83 × 1.69 in) |
| Weight | 13.0 kg (min) – 16.3 kg (max) |
| Management | iLO Standard with Intelligent Provisioning; optional iLO Advanced / Advanced Premium Security Edition; OneView Standard / Advanced |
Our lightning-fast online configurator lets you build a custom HPE ProLiant DL360 Gen10 in seconds—select CPU, memory, drives and adapters from the full QuickSpecs catalogue and receive an instant quote. Every order is double-checked by our technical team, guaranteeing component-level compatibility so you can focus on your workload, not the bill of materials.
The DL360 Gen10 supports the entire Intel Xeon® Scalable family in single- or dual-socket mode:
All ranges benefit from the DL360’s 24 DIMM slots (up to 3 TB), three PCIe 3.0 slots and flexible storage backplanes.
A complete internal redesign squeezes dual high-core CPUs, 24 DIMM slots and multiple storage backplane choices into a slim 1U chassis without compromising airflow or serviceability.
Whether you require dense virtualisation hosts, high-capacity storage nodes or NVMe-accelerated databases, the DL360 Gen10 scales to match your performance and capacity targets.
Uses hot-swap 2.5-inch drives for dense, power-efficient storage. Dual 2nd-Gen Intel Xeon® Scalable CPUs, two PCIe slots and up to 24 RDIMMs at 2933 MT/s.
Supports high-capacity 3.5-inch HDDs—ideal for cost-per-terabyte workloads. Dual processors, two PCIe slots and the same 24-slot memory architecture.
High-throughput backplane accepts NVMe, SAS and SATA drives in any mix. Dual Xeon Scalable CPUs, two PCIe slots and up to 24 RDIMMs.
Eight front 2.5-inch bays plus two optional rear SFF/uFF slots for boot or caching drives—perfect when you need OS disks isolated from the main storage pool.
