• H3C S6850 - 56HF L3 Ethernet Switch Host supports 48 SFP28 ports and 8 QSFP28 ports.
  • H3C S6850 - 56HF L3 Ethernet Switch Host supports 48 SFP28 ports and 8 QSFP28 ports.

H3C S6850 - 56HF L3 Ethernet Switch Host supports 48 SFP28 ports and 8 QSFP28 ports.

No.LS-6850-56HF
  • 48 × 25G SFP28 ports and 8 × 100G QSFP28 ports for high-density connectivity
  • Wire-speed forwarding capacity up to 4 Tbps
  • Supports VXLAN and MP-BGP EVPN for advanced Layer 2 and Layer 3 virtualization
  • IRF2 technology for intelligent resilience and scalability
  • Modular power supplies and fan trays for flexible deployment
  • Comprehensive data center features including PFC, ETS, and DCBX
  • Ideal for use as a TOR access switch or in aggregation layers
  • H3C S6850 - 56HF L3 Ethernet Switch Host supports 48 SFP28 ports and 8 QSFP28 ports.

Description

Product Description

The H3C S6850-56HF L3 Ethernet Switch (Model: LS-6850-56HF) is a high-performance, high-density switch designed for modern data centers and cloud computing networks. Featuring 48 SFP28 25G ports and 8 QSFP28 100G ports, it delivers exceptional forwarding capacity and supports advanced data center features.

With support for technologies like VXLAN, MP-BGP EVPN, and IRF2, the S6850-56HF ensures scalable, reliable, and flexible network architectures. Its modular design with removable power supplies and fan trays allows for easy maintenance and adaptability to various deployment scenarios.

Product Specifications
Model
LS-6850-56HF
Switch Type
L3 Ethernet Switch
Ports
48 × 25G SFP28, 8 × 100G QSFP28
Forwarding Capacity
Up to 4 Tbps
Dimensions (H × W × D)
43.6 × 440 × 460 mm
Weight
≤ 15 kg
Power Supply
Modular, supports 1+1 redundancy
Fan Trays
Modular, supports front-to-back/back-to-front airflow
Management Ports
1 × RJ-45, 1 × SFP
Console Ports
1 × Serial, 1 × Mini USB
USB Ports
1 × USB 2.0
Operating Temperature
0°C to 45°C
Operating Humidity
10% to 90% (non-condensing)
Compliance
IEEE 802.3by, IEEE 802.3ba, IEEE 802.3ae
