The Brocade G630 is a high-density building block designed to support NVMe storage environments, demanding workloads, and data center consolidation.
Adapt to storage growth and demanding workloads with the industry’s highest-density 128-port 32 Gbps Gen 6 Fibre Channel switch, delivering simple deployment and reduced TCO.
| Series | Model | Brief Description |
|---|---|---|
| Brocade G630 | G630-48 | 48 × 32 Gbps SWL SFP+ ports, base chassis |
| Brocade G630 | G630-96 | 96 × 32 Gbps SWL SFP+ ports via PoD |
| Brocade G630 | G630-128 | 128 × 32 Gbps SWL SFP+ ports full density with PoD |
Supports up to 128 ports in a 2 U chassis, the highest density in its class.
Expand from 48 to 128 ports on demand with PoD licensing for flexible growth.
Seamlessly integrates NVMe flash arrays with in-flight encryption and data compression.
Simple EZSwitchSetup deployment combined with proactive Fabric Vision® and IO Insight™ monitoring.
Delivers up to 2 Tbps aggregate bandwidth for demanding workloads.
| Fibre Channel Ports | 48–128 (PoD-expandable) |
|---|---|
| Port Speeds | Auto-negotiation at 16/32 Gbps |
| Aggregate Bandwidth | Up to 2 Tbps full-duplex |
| Form Factor | 2 U rack |
| Encryption & Compression | Built-in in-flight encryption and data compression |
| Monitoring | Fabric Vision® with IO Insight™ & VM Insight™ |
| Operating Temperature | 0 °C to 40 °C |
Select the Brocade G630 chassis and license bundles that best fit your SAN deployment:
| Item | Part Number | Description |
|---|---|---|
| 1 | BR-G630-24-32G-R | 24-port chassis, 32 Gbps SWL SFPs, Brocade, AC power, port-side exhaust airflow |
| 2 | BR-G630-48-32G-R | 48-port chassis, 32 Gbps SWL SFPs, Brocade, AC power, port-side exhaust airflow |
| 3 | BR-G630-96-32G-R | 96-port chassis, 32 Gbps SWL SFPs, Brocade, AC power, port-side exhaust airflow; Web tools, zoning, EGM, trunking, Fabric Vision®, Extended Fabric® |
| 4 | BR-G630-128-32G-R | 128-port chassis, 32 Gbps SWL SFPs, Brocade, AC power, port-side exhaust airflow; Web tools, zoning, EGM, trunking, Fabric Vision®, Extended Fabric® |
| 5 | MENT24PTPOD-32G | 24-port On-Demand license with 24 Brocade 32 Gbps SWL SFPs for Gen 6 mid-range switch |
| 6 | MENTEB5-01 | Enterprise Feature License Bundle (Trunking, Extended Fabric®, Fabric Vision®) on entry Fibre Channel switches |
